2025 ESSENTIAL HIHGLANDER DESIGN 1.1 18’8 FULL OFF-ROAD COMPOSITE CARAVAN
Introducing the all new Highlander. The 2025 Highlander has broken the mould with full sandwich panel construction – roof, front, rear, sides & floor creating unsurpassed insulation properties and strength. Riding on a 6” off road Australian built chassis with 2” riser, 17” Wheels & Mud Tyres, Full off road suspension and powered by ample solar and lithium, extended outback stays are now on your radar. The Highlander is a tough looking off road caravan with all the gear to get you there & back!

WEIGHTS
Tare: 2439 Kg
GTM: 2750 Kg
ATM: 2981 Kg
Ball: 231 Kg

CHASSIS
Linex Coated A-Frame & Black Painted Chassis
Titan X Off Road Suspension
265/70R17 Mud Tyres & 17” Alloy Rims
12” Electric Brakes to All Wheels
Jumbo 600 Toolbox inc. 2 x Slides, Integrated Stoneshield & Woodbox
6” Heavy Duty A-frame
A-Frame extended 650mm
6” Heavy Duty Chassis
2” Raiser
A-Frame Tap & Gas Regulator
Break Away Safety System
Heavy Duty 4-Arm Bumper
Spare Wheel Fitted to Bumper Bar Bolt On
DO35 Coupling
Wind Up Jack
8” Jockey Wheel
Drop Down Stabilizer Stands
Checkerplate Water Tank Guards
Galvanized Wheel Arches
Batteries Mounted on Chassis
Solid Fold Down Step – no step well

ELECTRICAL
Up to 4 x 220W Roof Mounted Solar with 30A Regulator MPPT depending on layout
Projecta PM435C 30A Battery Management System MPPT with 7” Colour Monitoring Screen
2 x 300AH Lithium Batteries Chassis Mounted
Extra Solar Controller 20A
External Solar Input
3000W Inverter wired to all GPO’s & Air Conditioner, Microwave & Washing Machine
30A DC to DC Charger
Fusion Stereo with 1 x Internal Speaker & 1 x External Speaker
12 Pin Trailer Plug
28” Smart TV on Wall Mounted Bracket
Roof Digital TV Antenna
Starlink Pass Through with GPO
12v/USB Socket & TV Point at Outside Picnic Table
240V 15AMP Inlet & 240V 10AMP Outlet
Double 240v Point & USB Point to wardrobes and lounge
2 x 12v Fans
1 x USB & USB-C point to angled kitchen splashback
Bulk Heads With Strip Lights
Reversing Camera & Car Monitor Kit
Circuit Breaker & Earth Leakage
Door Light & Entry Handle
LED External Lights
LED Work Lights Front 17”, Rear 11” & Off Side 7.5”
LED Lighting – Roof, Kitchen, Ensuite
Power Points (1x Kitchen, 1x Ensuite)
Reading Lights to Bedroom & Lounge with USB & USB-C
2-way switch from bedroom to Ensuite light
12v Benchtop Phone Charger beside Tables
3x Bug Annexe Light, 2x Evenly spaced 1 x above tunnel boot
Induction 2-Burner Cooktop Portable
4 in 1 Microwave Combo
Electric Motorised Footrests
Gusto 12v Dust Reduction System
PLUMBING
Dometic RUC8408X Compressor 216lt 2
Door Fridge/Freezer
2 x 95lt Water Tanks up to 20’ layout
3 x 95lt Water Tanks to 20’6 layout and above
Quick Fill Water Tank Fillers
Brass Manifold Water Tank Selector
Twin water level gauges
95lt Grey Water Tank
Checker Plate Tank Protection
A-Frame Mains Pressure Tap
Mains Pressure Water Inlet
Gas/Electric Hot Water System
12V Water Pump
Water Filter to sink with 3-1 Tap
Deep Bowl Stainless Kitchen Sink with Drain
China Vanity to Ensuite
Porcelain Bowl Toilet
External Gas Bayonet At Front Boot Door Side
Dual 9Kg Gas Bottles with Changeover Regulator

INTERNAL
12V Rangehood
Soft Close Drawers
Square Locking handles
Hidden latches to OHC
Full CNC Furniture & Partitions
Cabinet Hinge Bolted
Full Laminate Benchtop
Mirror in Ensuite
Frosted Glass Shower Door
2 Single Towel Rails and 1 Toilet Roll Holder
Washing Machine – not standard in family models
Electric Footrest Padded End
Innerspring Queen Mattress
Wardrobes Recessed Cutouts With Shelf
Grab Handle on Entry Wall at Door
Diesel Heater
Fire Extinguisher
Smoke Detector

EXTERNAL
Gree Roof Top Slimline 3.5Kw Air Conditioner with Smart WIFI Control
Awning
Full Fibreglass Sandwich Panel Construction Fully Insulated
Raven Coat 800mm Side Checker Plate
Raven Coat Checker Plate to lower front and rear
Raven Coat Checker Plate Wheel Spats
Checker Plate Protection to all Tanks
Solid Fold Down Step – no step well
Black External Trim
Updated 2025 Decal
Full through front tunnel boot with large access doors
Galvanised Rear Generator Compartment on certain layouts
Double Glazed Push Out Windows & Integrated Blinds
LED Roof Skylights with Blind & Flyscreen (1 or 2 depending on layout)
Radius Locking Security Main Door
2 x External Fold Down Picnic Table
12V Fan Hatch to Shower & Toilet
One key to access hatches and main door
5 year Structural Factory Warranty

TOW AWAY WITH
– 12 Months QLD Registration
– 5 Year Factory Warranty
– Customer Training Session
– Full Gas Bottles
